Summary:
This article outlines the supported microphones and their connectivity options for the TSL Studio. It includes step-by-step instructions for setting up these microphones with mobile devices such as iPhones using USBC/Lightning adapters.
Supported Microphones
| Brand / Type | Connectivity Type | Supported Since iOS App Version |
| Wireless Lavalier Microphone | USB-C/Lightning connector | 1.3.0 (released in April 22, 2024) |
| Comica Vimo Q | 3.5mm jack with USB-C/Lightning connector | 1.3.0 (released in April 22, 2024) |
| Rode Wireless GO | 3.5mm jack with USB-C/Lightning connector | 1.0.0 (released in August, 2023) |
| Wired Headphones | USB-C/Lightning connector | 1.0.0 (released in August, 2023) |
Comica Vimo Q Setup Instructions
To connect your Comica Vimo Q microphone with an iPhone, follow these steps:
1. Connect the Receiver: Use a 3.5 mm audio jack to USB-C / Lightning adapter to connect the microphone receiver to the iPhone. The Comica must be connected with Out A/B port.
2. Device Selection: When prompted by your iPhone, select Other Device.
Troubleshooting Common Issues
If you mistakenly select “Headphones” when prompted or encounter connection issues, follow these steps:
1. Disconnect the Microphone.
2. Navigate to Settings:
• Go to Settings > Sound & Haptics > Headphone Safety (located at the bottom).
3. Forget All Adapters:
•Select Lightning Adapters and choose Forget All Adapters.
4. Reconnect the Microphone.
Additional Information & Resources
For more details about the supported microphones, please refer to the following product links:
Apple EarPods with Lightning Connector
This article is intended to help users of TSL Studio set up and troubleshoot supported microphones efficiently.
